$1.000,00
Wall plate 86×86 AP | 802.11ax | 1.775 Gbps device rate | Dual-radio | 48 access users recommended | Max. 128 access users | 20 dBm transmit power | Smart antenna | 15 m optimal coverage range
Wall plate 86×86 AP | 802.11ax | 1.775 Gbps device rate | Dual-radio | 48 access users recommended | Max. 128 access users | 20 dBm transmit power | Smart antenna | 15 m optimal coverage range
| Parámetro | Especificación |
|---|---|
| Wi-Fi standard | 2.4G: 802.11b/g/n/ax5G: 802.11a/n/ac/ac Wave 2/ax |
| Installation Type | Junction Box (86 mm) |
| Optimal Signal Distance (m) | 15 |
| Max Number of Access Users | 128 |
| Recommended Number of Access Users | 48 |
| Maximum number of physical ports on the entire device | GE (RJ45) x 2, 10M/100M/1000M auto-sensing |
| Device Rate | 1.775 Gbps |
| Radio number | 2 |
| Maximum channel bandwidth [MHz] | Radio 0 (2.4 GHz): 40 MHzRadio 1 (5 GHz): 80 MHz |
| Maximum transmit power | 2.4G: 17 dBm/chain, 20 dBm (combined power)5G: 17 dBm/chain, 20 dBm (combined power) |
| MIMO spatial streams | Radio 0 (2.4 GHz): 2x2Radio 1 (5 GHz): 2×2 |
| Maximum power consumption [W] | 9.1 |
| Power supply mode | PoE |
| Input voltage range [V] | PoE: 802.3af |
| Service port surge protection | PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C |
| Dimensions without packaging (H x W x D) [mm(in.)] | 86 mm x 86 mm x 42.5 mm (3.39 in. x 3.39 in. x 1.67 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 98 mm x 117 mm x 73 mm (3.86 in. x 4.61 in. x 2. |
