$1.000,00
22 x 10/100/1000BASE-T PoE+ ports, 2 x 10/100/1000BASE-T ports, 2 x 10/100/1000/2.5GBASE-T Combo(PoE+), 2 x 10GE SFP+ ports | Packet forwarding rate: 73 Mpps | Switching capacity: 98 Gbit/s
22 x 10/100/1000BASE-T PoE+ ports, 2 x 10/100/1000BASE-T ports, 2 x 10/100/1000/2.5GBASE-T Combo(PoE+), 2 x 10GE SFP+ ports | Packet forwarding rate: 73 Mpps | Switching capacity: 98 Gbit/s
| Parameter | Especification |
|---|---|
| Switching capacity | 98 Gbit/s |
| Packet forwarding rate | 73 Mpps |
| GE RJ45 | 24 (22 PoE+) (1G/100M/10M) |
| 2.5GE Combo (RJ45 + SFP) | 2 (RJ45: 2.5G/1G/100M/10M; PoE+) (SFP: 2.5G/1G/100M) |
| 10G SFP+ | 2 (10G/1G/100M) |
| PoE | Supported |
| Maximum PoE power consumption [W] | 400 |
| Certification | EMC certification; Safety certification; Manufacturing certification |
| Chassis material | Metal |
| Static power consumption [W] | 19.56 |
| Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442 mm x 220 mm (1.72 in. x 17.40 in. x 8.66 in.)Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442 mm x 227 mm (1.72 in. x 17.40 in. x 8.94 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) |
| Installation type | Rack mounting, Desk mounting, Wall mounting |
| Weight without packaging [kg(lb)] | 2.81 kg (6.2 lb) |
| Weight with packaging [kg(lb)] | 3.72 kg (8.2 lb) |
| Typical power consumption [W] | 34.14 |
| Maximum power consumption [W] | – Without PoE: 39.40 W- Full PoE load: 484.27 W (PoE: 400 W) |
| Number of fans modules | 2 |
| Types of fans | Built-in |
| Long-term operating temperature [°C(°F)] | –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.) |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Power supply mode | AC built-in |
| Input voltage range [V] | – AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz- High-voltage DC input: 190 V DC to 290 V DC |
| Power supply surge protection [kV] | Differential mode: ±6 kV; common mode: ±6 kV |
| Heat dissipation mode | Air cooling for heat dissipation, intelligent fan speed adjustment |
| Airflow direction | Air intake from left and front, air exhaustion from right |
